Key Features
The UniFi USW-16-PoE is a 16-port Gigabit Layer 2 switch with eight PoE+ ports, enough to run a small camera or access point deployment without a separate injector. Two 1G SFP slots handle fiber uplinks, and the steel 1U chassis is fanless, so it can sit in an occupied room. Configuration and monitoring happen in the UniFi Network application alongside the rest of the site.
Tech Specs
- Ports: 16 x Gigabit Ethernet (RJ-45)
- PoE Ports: 8 x IEEE 802.3at PoE+
- PoE Budget: 42 W
- PoE Power per Port: Up to 32 W
- Uplinks: 2 x 1G SFP
- Switching Layer: Layer 2
- Switching Capacity: 36 Gbps
- Non-Blocking Throughput: 18 Gbps
- Management: UniFi Network application
- IGMP Snooping: Supported
- Port Mirroring: Supported
- Spanning Tree: Supported
- Network Standards: IEEE 802.1x
- Network Technology: 1000Base-X
- Media Type Supported: Optical Fiber
- Cooling: Fanless
- Form Factor: 1U rack mountable
- Chassis Material: SGCC steel
- Power Source: AC, internal power supply
- Input Voltage: 230 V AC
- Power Consumption: 60 W
- Weight: 6.17 lb
Warranty & Compliance
- Environmental Compliance: WEEE
