Key Features
A 24-port Gigabit switch with PoE+ on every port and a 300 W budget, powering cameras, access points, PoE lighting, and phones without a separate injector anywhere in the run. Non-blocking 48 Gbps switching keeps all 24 ports at wire speed, and auto-negotiation with Auto-MDI/MDIX means no configuration and no crossover cables. The fanless metal chassis mounts in a rack or sits on a desk in small and medium offices.
Tech Specs
- Ports: 24 x Gigabit RJ-45
- PoE Ports: 24 x PoE+
- PoE Budget: 300 W total
- PoE per Port: Up to 30 W
- PoE Standard: IEEE 802.3at
- Switching Capacity: 48 Gbps non-blocking
- Network Technology: Gigabit Ethernet (10/100/1000Base-T)
- Media Type: Twisted pair
- Auto-Negotiation: Supported
- Auto-MDI/MDIX: Supported
- Management: Unmanaged, no software or configuration required
- Port LEDs: Per-port activity and speed
- Chassis: Metal
- Cooling: Fanless
- Mounting: Desktop or rack
- Power Supply: Internal, 100 to 240 V AC 50/60 Hz
- Power Consumption: 359.50 W maximum
- Weight: 6.37 lb
Warranty & Compliance
- Lifetime manufacturer warranty
- ErP (Energy-related Products Directive) compliant
- REACH compliant
What's in the Box
- GS524PP Ethernet switch
- Power cord
- Rackmount kit
- Desktop rubber feet
- Installation guide
- Insight registration flyer
