Key Features
This 8-port multi-gigabit smart managed switch pairs four 10GbE RJ-45 ports with four 2.5GbE RJ-45 ports and two 10G SFP+ fiber uplinks. Layer 3 Lite static routing, 256 VLANs, and IPv4 and L4 access control lists suit small business networks feeding access points, multi-gig storage, and IP cameras. Optional NETGEAR Insight cloud management adds remote configuration.
Tech Specs
- Ports: 4 x 10GbE RJ-45 + 4 x 2.5GbE RJ-45
- Uplink Ports: 2 x 10G SFP+
- PoE: Not supported
- Switching Capacity: 140 Gbps non-blocking
- Switching Layer: Layer 3 Lite
- Routing: Static routing, 32 static routes
- VLANs: 256
- Multicast: IGMP snooping v1, v2, and v3 with querier
- Management: Smart managed, with optional NETGEAR Insight cloud management
- Monitoring: SNMP v1, v2c, and v3
- Access Control: IPv4 and L4-based ACLs
- Port Authentication: IEEE 802.1x
- Ethernet Technology: 10 Gigabit Ethernet
- Media Type: Twisted pair and optical fiber
- Power Supply: Internal
- Power Consumption: 47 W
- Acoustic Noise: 25 dB at 25 degrees C
- Form Factor: Desktop, also rack mountable
- Weight: 4.59 lb
Warranty & Compliance
- Warranty: NETGEAR Limited Lifetime Hardware Warranty
- Environmental Compliance: Battery Directive
- Environmental Certification: China Environmental United Certification Center (CEC)
What's in the Box
- MS510TXM Ethernet Switch
- Power Cord
- Mounting Kit
- Rubber Footpads for Tabletop Installation
- Quick Installation Guide
