Key Features
The Netgear GS752TXUPv3 is a 48-port Gigabit smart switch built for networks that need dense PoE power and high-speed interconnects. Sixteen PoE++ ports deliver up to 60 W each and the remaining 32 PoE+ ports up to 30 W, sharing a 640 W budget for IP cameras, VoIP phones, and wireless access points. Four dedicated 10G SFP+ uplinks add fiber capacity with redundancy and failover, and optional remote or cloud management keeps multi-site deployments simple.
Tech Specs
- Ports: 16 x Gigabit PoE++ RJ-45 + 32 x Gigabit PoE+ RJ-45
- Uplink Ports: 4 x 10G SFP+
- PoE Standard, Ports 1 to 16: IEEE 802.3bt, up to 60 W per port
- PoE Standard, Ports 17 to 48: IEEE 802.3at, up to 30 W per port
- PoE Budget: 640 W
- Switching Layer: Layer 3 Lite
- Static Routes: 32 (IPv4 and IPv6)
- Link Aggregation: LACP
- VLAN: Advanced VLAN and Private VLAN
- Multicast VLAN Registration: Supported
- Access Control Lists: L2, L3, and L4
- Spanning Tree: Supported
- QoS: DiffServ
- DHCP: DHCP Relay
- PoE Self-healing: Supported
- Management: Smart managed with optional remote and cloud management
- Acoustics: 26.8 dBA to 37.3 dBA at 25°C ambient
- Form Factor: Rack mountable, tabletop
Warranty & Compliance
- Warranty: Limited lifetime
What's in the Box
- GS752TXUPv3 Ethernet Switch
- AC Power Cord with C13 Connector
- Brackets and Screws for Rack Mounting
- Rubber Footpads for Tabletop Installation
- Rubber Protection Caps
- Installation Guide
