Key Features
This 1U fully managed fiber switch pairs 16 x 25G SFP28 access ports with four 100G QSFP28 uplinks for dense aggregation across long cable runs. A 420 W internal supply and a modular supply slot provide 1+1 redundancy, while Virtual Chassis stacking with non-stop forwarding keeps traffic moving through a failover. A full Layer 3 routing set and purpose-built AV tooling suit Pro AV and midsize IT networks.
Tech Specs
- Access Ports: 16 x 25GBASE-X SFP28
- Uplink Ports: 4 x 100GBASE-X QSFP28
- Switching Capacity: 1.6 Tbps
- Forwarding Rate: 1,190.4 Mpps
- Switching Layer: Layer 3
- Routing: Static, policy based, and dynamic
- Ethernet Technology: 100 Gigabit Ethernet
- Media Type: Optical fiber
- Network Standards: IEEE 802.1BA (AVB)
- Stacking: Virtual Chassis with non-stop forwarding and hitless failover
- Multicast: NETGEAR IGMP Plus
- Management: AV User Interface and Engage Controller
- Monitoring: SNMP
- Power Supply: 420 W internal
- Power Redundancy: One modular power supply slot for 1+1 redundancy
- Compatible Power Modules: APS600Wv3, APS1200Wv2, or APS2000Wv2
- Power Consumption: 143.4 W
- Input Voltage: 230 V AC
- Plug Type: C14
- Acoustic Noise: 33.4 dB in Quiet Mode at 25 degrees C
- Rack Units: 1U
- Weight: 17.11 lb
Warranty & Compliance
- Warranty: NETGEAR ProSAFE Limited Lifetime Hardware Warranty
- Hardware Replacement: Lifetime Next Business Day
- Technical Support: 90 days phone and email, lifetime online chat
