Key Features
This 1U fully managed AV over IP switch pairs 24 Gigabit PoE+ ports with two additional Gigabit ports and four 10G SFP+ uplinks. A 480 W PoE budget powers cameras, encoders, and displays at up to 30 W each, while the 10G fiber uplinks carry aggregated streams back to the core. A full Layer 3 routing set with static, RIP, and PIM plus a dedicated AV interface suit venues, broadcast studios, and midsize enterprise AV racks.
Tech Specs
- PoE Ports: 24 x Gigabit PoE+ RJ-45
- Additional Ports: 2 x Gigabit RJ-45
- Uplink Ports: 4 x 10GBASE-X SFP+
- PoE Standard: IEEE 802.3at (PoE+)
- Maximum PoE per Port: 30 W
- PoE Budget: 480 W
- Switching Layer: Layer 3
- Routing: Static, RIP, and PIM
- DHCP: DHCP server
- Ethernet Technology: 10 Gigabit Ethernet
- Media Type: Twisted pair and optical fiber
- Multicast: NETGEAR IGMP Plus
- AV Profiles: Dante, Q-SYS, AES67, NVX, SVSI, and NDI
- Management: AV web GUI, IT web GUI, CLI, console, Telnet, and SSH
- Monitoring: SNMP, sFlow, and RSPAN
- Power Supplies Installed: 1
- Power Consumption: 46.8 W
- Plug Type: C14
- Rack Units: 1U
- Weight: 12.02 lb
Warranty & Compliance
- Warranty: NETGEAR ProSAFE Limited Lifetime Hardware Warranty
- Hardware Replacement: Lifetime Next Business Day
- Technical Support: 90 days phone and email, lifetime online chat
- Energy Efficiency: Energy-related Products Directive (ErP)
- Environmental Compliance: REACH
What's in the Box
- M4250-26G4XF AV Line Managed Switch
- Power Cord
- RJ-45 to DB9 Serial Console Cable
- USB Type-C to USB-A 2.0 Console Cable
- Rubber Caps for the SFP and SFP+ Sockets
- Rubber Footpads for Tabletop Installation
- Two Standard Brackets and Screws for Two-post Rack Mount
- Two Longer Brackets for Recessed Two-post Rack Mount
- Installation Guide
