Description
The HPE Instant On AP22D is a compact dual‑band Wi‑Fi 6 access point designed for small and medium businesses. It delivers up to 1.7 Gbps aggregate wireless throughput over a 2.5 GbE uplink, supports 75+ wireless devices, and powers desk‑side deployments with four 1 GbE downlink ports and 2× 15 W PoE on those ports. Manage it via the Instant On app or portal for simple guest and employee network control.
Tech Specs
- Uplink Port: 1 × 2.5 GbE
- Downlink Ports: 4 × 1 GbE
- Total RJ45 Ports: 5
- PoE Budget: 2 × 15 W on downlink ports (802.3af)
- Wireless Standard: 802.11ax (Wi‑Fi 6)
- Frequency Band: Dual‑band (2.4 GHz / 5 GHz)
- Antenna Configuration: 2 internal antennas
- OFDMA: Yes
- MU‑MIMO: Yes
- Target Wake Time (TWT): Yes
- Aggregate Wireless Throughput: Up to 1.7 Gbps
- Management: Instant On app/portal for network management
- Mounting Options: Desk or wall mounting with included mounting kits
Warranty & Compliance
- Warranty / Install Support: 90‑day phone and chat install support
What's in the Box
- Desk/Wall mounting kits included
