Key Features
The HPE Instant On 1960 24G PoE is a smart-managed Layer 2+ switch for a growing office that runs powered devices. Twenty-four Gigabit PoE ports share a 370 W budget, enough for access points, cameras, VoIP phones, and a handful of 60 W pan-tilt-zoom cameras, while two 10GBASE-T and two 10G SFP+ uplinks connect servers and storage at 10G. Up to four units stack under a single IP address and are managed from the Instant On mobile app, the cloud portal, or the local web GUI.
Tech Specs
- Ports: 24 x Gigabit PoE RJ-45
- Uplink Ports: 2 x 10GBASE-T RJ-45
- SFP+ Slots: 2 x 10G SFP+
- PoE Budget: 370 W
- Class 4 PoE Ports (30 W): 20
- Class 6 PoE Ports (60 W): 4
- PoE Standards: IEEE 802.3at, IEEE 802.3bt
- Maximum Data Rate: 10 Gbps
- Switching Layer: Layer 2+
- Management: Smart-managed
- Management Interfaces: Instant On mobile app, cloud portal, local web GUI
- Stacking: Up to 4 switches under one IP address
- VLAN Support: IEEE 802.1Q
- Power Input: 230 V AC
- Power Consumption: 80 W
- Mounting: 19-inch rack, wall, or tabletop
- Weight: 10.36 lb
Warranty & Compliance
- Warranty: Limited lifetime
